Road subgrade design in Anchorage must account for the region's unique combination of frost action, seasonal thaw, and variable glacial till deposits. The AASHTO Guide for Design of Pavement Structures (1993) and IBC 2021 set the framework, but local practice demands a deeper look at the subgrade's response to freeze-thaw cycles. In our experience, the most reliable designs start with a thorough characterization of the soil profile using the ensayo CBR to measure soaked California Bearing Ratio, and the límites de Atterberg to identify the plasticity and shrink-swell behavior of silty clays common in the Anchorage Bowl. These tests provide the baseline parameters for the structural number calculation under AASHTO methodology.
Thaw-weakening can cut subgrade modulus in half. Without a proper soak-CBR and frost classification, the pavement design is incomplete.
Methodology and scope
- Classifying soil according to the Unified Soil Classification System (ASTM D2487).
- Determining the maximum dry density and optimum moisture content via Proctor tests (ASTM D698).
- Running soaked CBR tests on specimens compacted at OMC to simulate worst-case spring conditions.
Local considerations
Anchorage has grown rapidly since the 1964 Great Alaska Earthquake, with much of the new development pushing into areas underlain by Bootlegger Cove Clay and other frost-susceptible silts. Road subgrade design in these zones is particularly challenging because seasonal heave and differential settlement can crack pavements within two to three winters. The risk is not just structural: water infiltrates through pavement cracks, accelerates frost action, and triggers deeper failure. A proper subgrade investigation that includes drenaje vial and drainage layer design is essential to control moisture and extend pavement life in this climate.
Applicable standards
AASHTO Guide for Design of Pavement Structures (1993, 2002 Supplement), ASTM D1883-21 (Standard Test Method for CBR of Laboratory-Compacted Soils), IBC 2021 – Chapter 18 (Soils and Foundations) & Chapter 33 (Site Work), FHWA-RD-97-031 (Frost Action in Soils – Classification and Mitigation)
Associated technical services
Subgrade Characterization & CBR Testing
Complete soil classification including grain size, Atterberg limits, and Proctor compaction. Soaked CBR tests under spring-thaw conditions to determine the design subgrade strength. Results are reported with Mr correlation for flexible pavement design per AASHTO.
Frost Susceptibility & Drainage Assessment
Evaluation of frost-heave potential using the USACE frost classification system. Determination of the depth of frost penetration and thaw-weakening factors. Integration with drainage layer design to mitigate water accumulation in the subgrade.
Typical parameters
Frequently asked questions
How is the soaked CBR test different from the unsoaked CBR for road subgrade design?
The soaked CBR simulates the worst-case moisture condition after spring thaw, when the subgrade is saturated and weakest. In Anchorage, where frost action drives water upward, the soaked value is often 30% to 50% lower than the unsoaked value. AASHTO and FHWA recommend using the soaked CBR for design unless the pavement is placed on a free-draining granular base that prevents water accumulation.
What frost-susceptibility classification does FHWA use for subgrade soils?
FHWA classifies soils into four groups (F1 to F4) based on the percentage of fines passing the No. 200 sieve and the plasticity index. F1 soils are sands with less than 6% fines and low frost heave; F4 includes silts and clays with more than 20% fines and high heave potential. Most Anchorage glacial tills fall into F2 or F3, requiring a thaw-weakening reduction factor of 0.4 to 0.6 in the structural design.
Can road subgrade design be done without a thaw-weakening factor in Anchorage?
Technically you can, but it is not recommended. Without applying a thaw-weakening factor, the design assumes the subgrade retains its summer strength year-round. Given that Anchorage experiences an average of 2,500 to 3,500 freezing degree-days per winter, ignoring seasonal softening leads to premature pavement failure. IBC and AASHTO both allow site-specific adjustments; we always include the factor when the soil is frost-susceptible.
